193/267

Building Technologies Basic documentation LMV37.4... CC1P7546en

27 Parameter level 17.12.2018

Adopt the value!



reset

ESC



Discard the change!

mi n

Bild 65/0707

Press

reset

to return to editing mode.

The value set will be adopted.

mi n

Bild 74/0707

Press

ESC

to return to the parameter

level.

Display: Parameter 162: flashes, characters

._._

do not.



Note

To detect potential display errors, the

value is displayed 1 place shifted to the

right.

Display: Value 0

ESC

mi n

Bild 70/0707

Press

ESC

to return to the parameter level.

PArAmeter 100: for general.

Default Chapter3
- Table of Contents3
