217/267

Building Technologies Basic documentation LMV37.4... CC1P7546en

27 Parameter level 17.12.2018

mi n

Bild 117/0707

Phase Traveling to ignition position

mi n

Bild 119/0707

Phase Preignition

mi n

Bild 120/0707

Phase 1st safety time (ignition transformer ON)

mi n

Bild 122/0707

Phase Interval 1

and

as well as

and

mi n

Bild 149/0707

Ignition position P0 can be set only when

symbol ▲ or ▼ is no longer highlighted.

Keep

depressed and, for VSD

and

Press

or to adjust the value.

When symbol ▲ or ▼ is no longer

highlighted, the next curvepoint P1 can be

selected with
