230/267
Building Technologies Basic documentation LMV37.4... CC1P7546en
28 Parameter list LMV37.4 17.12.2018
Par. Parameter Number of Type Edit Value range Increment Default Password level
no. elements Min. Max. setting write read
262 Oil: Prepurging
0 = inactive
1 = active
1 Selection edit 0 1 1 1 OEM OEM
265 Oil: Prepurge time 1 Time edit LMV37.400Ax: 15 s
LMV37.420Ax: 5 s
60 min 0,2 s LMV37.400Ax: 15 s
LMV37.420Ax: 30 s
HF HF
266 Oil: Preignition time 1 Time edit 0,6 s 60 min 0,2 s 2 s HF HF
267 Oil: First safety time 1 Time edit 1 s 15 s 0,2 s 5 s OEM OEM
269 Oil: Time to respond to pressure faults within first and
second safety time
1 Time edit 0,4 s 14,6 s 0,2 s 1,8 s OEM OEM
270 Oil: Interval 1 1 Time edit 0,4 s 60 min 0,2 s 2 s HF HF
271 Oil: Second safety time 1 Time edit 1 s 15 s 0,2 s LMV37.400Ax: 5 s
LMV37.420Ax: 10 s
OEM OEM
272 Oil: Interval 2 1 Time edit 0,4 s 60 s 0,2 s 2 s HF HF
273 Oil: Afterburn time 1 Time edit 0,2 s 60 s 0,2 s 8 s HF HF
274 Oil: Postpurge time (no extraneous light test) 1 Time edit 0,2 s 108 min 0,2 s LMV37.400Ax: 0,2 s
LMV37.420Ax: 15 s
HF HF
276 Oil: Input pressure switch-min
1 = active from phase 38
2 = active from safety time
1 Selection edit 1 2 1 1 HF HF
277 Oil: Input pressure switch-max/POC
1 = pressure switch-max
2 = POC
3 = not used
4 = additional speed-dependent air pressure switch
1 Selection edit 1 4 1 1 HF HF
279 Oil: Forced intermittent operation
0 = inactive
1 = active
1 Selection edit 0 1 1 1 OEM HF
280 Repetition limit value loss of flame
1 = no repetition
2 = 1 repetition
Recharging time:
After the
Operation phase
1 Std_u8 edit 1 2 1 LMV37.400Ax: 2
LMV37.420Ax: 1
OEM OEM
Note!
Parameters 280 and 380 refer to the same
value.
