72/267

Building Technologies Basic documentation LMV37.4... CC1P7546en

7 Basic unit LMV37.4 17.12.2018

Gas (always modulate)

Pilot ignition 1

Gp2

V1 V2

7548f01e

0309

Figure 45: Gas – fuel valve control

Legend for fuel trains:

*) Not used

1) For the valve proving function, the

pressure switch-min is located

between the fuel valve V1 / V2

HO Heavy oil

LO Light oil

No Normally Open

P LT Valve proving

Pmax Pressure switch-max

Pmin Pressure switch-min

PV Pilot valve

SA Actuator

SV Safety valve (outdoors)

TSAx Safety time

V Fuel valve

Fuel valve control
