90/267
Building Technologies Basic documentation LMV37.4... CC1P7546en
7 Basic unit LMV37.4 17.12.2018
Symbols
Permissible position range
In Standby mode: Actuator is allowed to travel within the permissible
position range, but is always driven to the home position; must be in the
home position for phase changes
0°/10%
Position as supplied (0°)
90°/100% Actuator fully open (90°)
Input/output signal 1 (ON)
Input/output signal 0 (OFF)
Input permissible signal 1 (ON) or 0 (OFF)
*) Alternative to pressure switch-max
**) Only with valve proving via pressure switch-min
