92/267
Building Technologies Basic documentation LMV37.4... CC1P7546en
8 Selection of operating mode 17.12.2018
Operating mode parameter 201 Fuel train Fuel-air ratio control Fuel actuator Air actuator Feedback signal VSD
Description
1 G mod
Modulating
electronic
● ● ●
Gas direct ignition, electronic modulating ratio control.
Optional with VSD with speed feedback signal
2 Gp1 mod
Modulating
electronic
● ● ●
Gas pilot ignition 1, electronic modulating ratio control.
Optional with VSD with speed feedback signal
3 Gp2 mod
Modulating
electronic
● ● ●
Gas pilot ignition 2, electronic modulating ratio control.
Optional with VSD with speed feedback signal
4 Lo mod
Modulating
electronic
● ● ●
Oil direct ignition, electronic modulating ratio control.
Optional with VSD with speed feedback signal
5 Lo 2-stage 2-stage ● ●
Oil direct ignition, electronic 2-stage ratio control.
Optional with VSD with speed feedback signal
6 Lo 3-stage 3-stage ● ●
Oil direct ignition, electronic 3-stage ratio control.
Optional with VSD with speed feedback signal
7 G mod pneu
Modulating
pneumatic
●
Gas direct ignition, pneumatic modulating ratio control.
Optional with VSD.
8
Gp1 mod
pneu
Modulating
pneumatic
●
Gas pilot ignition 1, pneumatic modulating ratio control.
Optional with VSD.
9
Gp2 mod
pneu
Modulating
pneumatic
●
Gas pilot ignition 2, pneumatic modulating ratio control.
Optional with VSD.
10 LoGp mod
Modulating
electronic
● ● ●
Oil pilot ignition, electronic modulating ratio control.
Optional with VSD with speed feedback signal
11 LoGp 2-stage 2-stage ● ●
Oil pilot ignition, electronic 2-stage ratio control.
Optional with VSD with speed feedback signal
12
Lo mod 2 fuel
valves
Modulating
electronic
● ● ●
Oil direct ignition, 2 fuel valves, electronic modulating ratio control.
Optional with VSD with speed feedback signal
13
LoGp mod 2
fuel valves
Modulating
electronic
● ● ●
Oil pilot ignition, 2 fuel valves, electronic modulating ratio control.
Optional with VSD with speed feedback signal
14
G mod pneu
without
actuator
Modulating
pneumatic
Gas direct ignition, without actuator, pneumatic modulating ratio
control. Optional with VSD.
15
Gp1 mod
pneu without
actuator
Modulating
pneumatic
Gas pilot ignition 1, without actuator, pneumatic modulating ratio
control. Optional with VSD.
16
Gp2 mod
pneu without
actuator
Modulating
pneumatic
Gas pilot ignition 2, without actuator, pneumatic modulating ratio
control. Optional with VSD.
17
Lo 2-stage
without
actuator
2-stage ●
Oil direct ignition, without actuator, electronic 2-stage ratio control.
Optional with VSD with speed feedback signal
18
Lo 3-stage
without
actuator
3-stage ●
Oil direct ignition, without actuator, electronic 3-stage ratio control.
Optional with VSD with speed feedback signal
19
G mod only
gas actuator
Modulating
electronic
● ●
Gas direct ignition, only gas actuator. modulating ratio control.
Optional with VSD with speed feedback signal
20
Gp1 mod only
gas actuator
Modulating
electronic
● ●
Gas pilot ignition 1, only gas actuator. modulating ratio control.
Optional with VSD with speed feedback signal
21
Gp2 mod only
gas actuator
Modulating
electronic
● ●
Gas pilot ignition 2, only gas actuator. modulating ratio control.
Optional with VSD with speed feedback signal
22
Lo mod only
oil actuator
Modulating
electronic
● ●
Oil direct ignition, only oil actuator. modulating ratio control.
Optional with VSD with speed feedback signal
