Siemens SIMATIC ET 200SP User Manual

Maintenance
9.8 Removing and inserting the CFast card
CPU 1515SP PC (F)
100 Manual, 05/2017, A5E32701806-AC
9.8
Removing and inserting the CFast card
Introduction
CPU 1515SP PC (F) has one slot for a CFast card. On this card, you will find the operating
system, your Runtime software and, after configuration, the project.
Seal the cover for the CFast card to protect the system against unauthorized access.
You must remove the CFast card before you send in the CPU, for example, for repair.
Requirements
● CPU 1515SP PC (F) is de-energized.
Procedure – Removing the CFast card
1. Remove the seal.
2. Open the cover, using a screwdriver if necessary.
3. Press onto the CFast card.
The card is pressed out of the slot.
4. Pull the card out of the slot.
To do this, grip the rib on the underside of the memory card.
Procedure – Inserting the CFast card
1. Open the cover of the slot, using a screwdriver if necessary.
2. Insert the CFast card into the slot.
3. Press the CFast card into the slot.
The CFast card is properly inserted if the cover can be closed without any resistance.
4. Close the cover.
NOTICE
Unauthorized access
Seal the cover with lead to protect the CFast card with the operating system of the
CPU 1515SP PC (F) against unauthorized access.
