Siemens SIMATIC ET 200SP User Manual

CPU 1515SP PC (F)
34 Manual, 05/2017, A5E32701806-AC
Installing
4
4.1
Basics
Introduction
The CPU 1515SP PC (F) is an open operation resource. This means that you may only
install it in enclosures, cabinets or electrical operating areas. These housings, cabinets or
electrical operating areas must only be accessible with a key or tool. Access may only be
possible for instructed or authorized personnel.
Installation location
CPU 1515SP PC (F) must be installed in a suitable enclosure or suitable control cabinet with
at least IP54 degree of protection according to EN 60529 and the ambient conditions for the
operation of the equipment must be taken into consideration.
Installation position
You can install the ET 200SP distributed I/O system in any position. The preferred mounting
position is horizontal mounting on a vertical wall.
The restrictions regarding ambient temperature and maximum configuration apply to the
CPU 1515SP PC (F) depending on the mounting position.
NOTICE
Damage to the modules
Modules can be damaged if exposed to ambient temperatures higher than permitted.
The following ambient temperatures must not be exceeded during operation:
• Horizontal mounting
– 60 °C for an installation with up to 32 I/O modules.
– 55 °C for an installation with up to 64 I/O modules.
• Vertical mounting
–
50 °C for an installation with up to 32 I/O modules.
For more detailed information, refer to section Mechanical and climatic ambient conditions
(Page 108)

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
