Technical data
10.5 Information on insulation, protection class, degree of protection and rated voltage
CPU 1515SP PC (F)
110 Manual, 05/2017, A5E32701806-AC
Climatic ambient conditions
You may use the CPU 1515SP PC (F) under the following climatic, ambient conditions.
Table 10- 10 Climatic ambient conditions
Ambient conditions
Permissible range
Comments
Temperature:
Horizontal mounting position:
• from 0 to 60 °C
For configuration with 32 I/O modules and 3 x
100 mA USB load
• from 0 to 55 °C
For configuration with 64 I/O modules and 2 x
500 mA + 1 x 100 mA USB load
Vertical installation:
• 0 to 50 °C
For configuration with 32 I/O modules and 3 x
100 mA USB load
Permitted temperature change 10 K/h -
Relative humidity from 10 to 95% Without condensation, corresponds to rela-
tive humidity (RH) class 2 according to IEC
61131 part 2
Barometric pressure 1080 hPa to 795 hPa Corresponds to an altitude of -1000 m
to 2000 m
Concentration of pollutants SO
2
: <0.5 ppm;
RH <60 %, no condensation
H
2
S: <0.1 ppm;
RH <60 %, no condensation
-
ISA-S71.04 severity level G1; G2; G3
-
10.5
Information on insulation, protection class, degree of protection and
rated voltage
Insulation
The insulation is designed according to the requirements of EN 61131-2: 2007.
Note
For modules with 24 V DC supply voltage, the electrical isolation is designed for max. 60 V
AC / 75 V DC and basic insulation is designed according to E
N 61131-2: 2007.
Pollution degree/overvoltage category according to IEC 61131
● Pollution degree 2
● Overvoltage category: II
