Technical data
10.4 Mechanical and climatic ambient conditions
CPU 1515SP PC (F)
Manual, 05/2017, A5E32701806-AC
109
Mechanical ambient conditions
The table below shows the mechanical ambient conditions in the form of sinusoidal
oscillations.
Table 10- 8 Mechanical ambient conditions
Frequency band
CPU 1515SP PC (F)
5 ≤ f ≤ 8.4 Hz
3.5 mm amplitude
8.4 ≤ f ≤ 150 Hz 1 g constant acceleration
10 ≤ f ≤ 60 Hz
0.35 mm amplitude
60 ≤ f ≤ 1000 Hz
• 1 g constant acceleration (with BusAdapter BA 2×RJ45)
• 2 g
constant acceleration (with BusAdapter BA 2×FC)
Test of mechanical ambient conditions
The table below provides important information with respect to the type and scope of the test
of ambient mechanical conditions.
Table 10- 9 Test of mechanical ambient conditions
Condition tested
Test Standard
Comment
Vibration Vibration test accord-
ing to IEC 60068-2-6
(sine)
Type of oscillation: Frequency sweeps with a rate of change of 1 oc-
tave/minute.
BA 2×RJ45
• 5 Hz ≤ f ≤ 8.4 Hz, 3.5 mm constant amplitude
• 8.4 Hz ≤ f ≤ 150 Hz, 1 g constant acceleration
BA 2×FC
• 10 Hz ≤ f ≤ 60 Hz, 0.35 mm constant amplitude
• 60 Hz ≤ f ≤ 1000 Hz, 2 g constant acceleration
Duration of vibration: 10 frequency sweeps per axis in each of 3 vertically
aligned axes
Shock Shock, tested accord-
ing to IEC 60068-2-27
Type of shock: Half-sine
Shock intensity: 150 m/s
2
peak value, 11 ms duration
Direction of shock: 3 shocks in each direction (+/-) at each of 3 vertically
aligned axes
