Siemens SIMATIC ET 200SP User Manual

Technical data
10.7 Module data
CPU 1515SP PC (F)
Manual, 05/2017, A5E32701806-AC
121
6ES7677-2AA40-0AA0
I/O / Options
I/O
•
SD card
optional for additional mass storage
Dimensions
Width
160 mm
Height
117 mm
Depth
75 mm
Weights
Weight, approx.
0.83 kg
10.7.4
CPU 1515SP PC, system version WES7 P 64Bit 4GB RAM
CPU 1515SP PC, system version WES7 P 64Bit 4GB RAM
6ES7677-2AA41-0FB0
General information
Product type designation
CPU 1515SP PC
HW release number
FS05
Firmware version
V2.1
Engineering with
STEP 7 TIA Portal can be configured/integrated as of version
V14 SP1
PC configuration
Processor
Dual-Core 1 GHz, AMD G Series APU T40E
Main memory
4 GB RAM
Flash disk
30 GB
Operating systems
Windows Embedded Standard 7 P 64 bit
Installed SW
Visualization
No
Controller
S7-1500 Software Controller CPU 1505SP V2.1
Operator controls
Mode selector
1
Supply voltage
Type
of supply voltage 24 V DC
Low limit of permitted range (DC)
19.2 V
High limit of permitted range (DC)
28.8 V
Reverse polarity protection
Yes
Power and voltage failure backup
Power/voltage failure backup time
5 ms
