Technical data
10.7 Module data
CPU 1515SP PC (F)
120 Manual, 05/2017, A5E32701806-AC
6ES7677-2AA40-0AA0
1st interface
Interface hardware
Number of ports
2
integrated switch
Yes
RJ 45 (Ethernet)
Yes; via BusAdapter BA 2x RJ45
•
Transmission rate, max.
100 Mbps
•
Industrial Ethernet status LED
Yes
2nd interface
Interface hardware
Number of ports
1
RJ 45 (Ethernet)
Yes; integrated
•
Transmission rate, max.
1000 Mbps
•
Industrial Ethernet status LED
No
3rd interface
Interface hardware
RS 485
Yes; via CM DP module
Interface hardware
RJ 45 (Ethernet)
100 Mbps
Yes; for 1st Interface X1
1000 Mbps
Yes; for 2nd Interface X2
Autonegotiation
Yes
Autocrossing
Yes
RS 485
Transmission rate, max.
12 Mbps
Ambient conditions
Ambient temperature in operation
Min.
0 °C
Max.
Up to 60 °C with max. 32 ET 200SP modules and
3x 100 mA USB load; up to 55 °C with max 64 ET 200SP
modules and 2x max. 500 mA and 1x max. 100 mA USB
load
Horizontal installation, min.
0 °C
Horizontal installation, max.
60 °C
Vertical installation, min.
0 °C
Vertical installation, max.
50 °C; with max. 32 ET 200SP modules and 3x 100 mA
USB load
Ambient temperature during storage / transport
Min.
-40 °C
Max.
70 °C
