Siemens SIMATIC ET 200SP User Manual

Technical data
10.3 Shipping and storage conditions
CPU 1515SP PC (F)
108 Manual, 05/2017, A5E32701806-AC
10.3
Shipping and storage conditions
Introduction
The CPU 1515SP PC (F) exceeds requirements in terms of shipping and storage conditions
according to IEC 61131-2. The following information applies to modules that are shipped
and/or stored in their original packaging.
Table 10- 7 Shipping and storage conditions for modules
Type of condition
Permissible range
Free fall (in shipping package)
≤1 m
Temperature From -40 °C to +70 °C
Barometric pressure 1080 hPa to 660 hPa (corresponds to an altitude of -1000 m
to 3500 m)
Relative humidity 5% to 95%, without condensation
Sinusoidal vibrations according to
IEC 60068-2-6
5 - 8.4 Hz: 3.5 mm
8.4 - 500 Hz: 9.8 m/s
2
Shock according to IEC 60068-2-27
250 m/s
2
, 6 ms, 1000 shocks
10.4
Mechanical and climatic ambient conditions
Note
Restrictions
Deviating from the ambient conditions for the ET
200SP distributed I/O system, the following
restrictions app
ly to the CPU 1515SP PC (F):
•
Mechanical ambient conditions:
– 2 g constant acceleration when using the BusAdapter BA 2×FC
•
Ambient temperature:
– 0 to 60 °C for horizontal installation with maximum 32 I/O modules
– 0 to 55 °C for horizontal installation with maximum 64 I/O modules
–
0 to 50 °C for vertical installation with maximum 32 I/O modules
Operating conditions
CPU 1515SP PC (F) is designed for stationary use in weather-proof locations. The operating
conditions exceed the requirements according to DIN IEC 60721-3-3:
● Class 3M3 (mechanical requirements)
● Class 3K3 (climatic requirements)

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
