Commissioning
7.2 Initial commissioning
CPU 1515SP PC (F)
50 Manual, 05/2017, A5E32701806-AC
Initial commissioning
Requirements
The following conditions must be met before you commission the open controller for the first
time.
● CPU 1515SP PC (F) is mounted.
● The CFast card is inserted.
● No data carriers are connected via USB.
● The following hardware is available: A monitor, a USB keyboard, a USB mouse
1. Connect a monitor via a DVI-I cable.
2. Connect a keyboard and a mouse to the CPU via USB.
3. Connect the power supply.
→ The PWR LED lights up yellow first, then green.
→ The device carries out the hardware initialization.
4. Wait until the Siemens logo disappears from the screen.
5. Follow the instructions on the screen to configure the device
If you change the default values in the BIOS Setup or switch off the device during the
installation, the installation will be disrupted and the operating system will not be installed
correctly. The operational reliability of the device and the plant is endangered.
Do not switch of the device during the entire installation process. Do not change the default
values in the BIOS Setup.
● The WES7 operating system is installed.
● WES7 P: The Multitouch functions are available.
● The operating system's start screen is displayed after each startup.
● A login window appears if a password was entered during the initial commissioning.
