Siemens SIMATIC ET 200SP User Manual

Technical data
10.7 Module data
CPU 1515SP PC (F)
118 Manual, 05/2017, A5E32701806-AC
6ES7677-2FA31-0EB0
Ambient temperature during storage / transport
Min.
-40 °C
Max.
70 °C
I/O / Options
I/O
•
SD card
optional for additional mass storage
Dimensions
Width
160 mm
Height
117 mm
Depth
75 mm
Weights
Weight, approx.
0.83 kg
10.7.3
CPU 1515SP PC, system version WES7 E 32Bit 4GB RAM - spare part
CPU 1515SP PC, system version WES7 E 32Bit 4GB RAM - spare part
6ES7677-2AA40-0AA0
General information
Product type designation
CPU 1515SP PC
Engineering with
STEP 7 TIA Portal can be configured/integrated as of version
as of STEP 7 V14
PC configuration
Processor
Dual-Core 1 GHz, AMD G Series APU T40E
Main memory
4 GB RAM
Installed SW
Visualization
No
Controller
No
Operator controls
Mode selector
1
Supply voltage
Type of supply voltage
24 V DC
Low limit of permitted range (DC)
19.2 V
High limit of permitted range (DC)
28.8 V
Reverse polarity protection
Yes
Power and voltage failure backup
Power/voltage failure backup time
5 ms

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
