Maintenance
9.4 Restoring delivery state using USB stick
CPU 1515SP PC (F)
Manual, 05/2017, A5E32701806-AC
95
9.4
Restoring delivery state using USB stick
Introduction
You can use the Restore menu to create a bootable USB stick in order to restore the original
software of the CPU 1515SP PC (F).
Use the SIMATIC IPC Service USB FlashDrive (6AV7672-8JD02-0AA0) for the creation.
Preparing bootable USB stick using PC
NOTICE
Data loss
If you transfer the data from the Restore-DVD to the USB stick, all existing data on the USB
stick is deleted.
You should back up the data on the USB stick before you create the Restore USB stick.
Transferring Restore DVD data to the USB stick
1. Place the Restore DVD into the DVD drive of a PC.
2. Double-click the CD_Menu.exe file in the root directory of the DVD.
3. Select the option " Create USB flash drive".
4. When all the data has been transferred, remove the Restore USB stick safely from the
PC.
Note
If you disturb the User
-Interface window during the process (for example, by a mouse click in
the window), the process continues unchanged even if no
reaction is recognizable within the
tool interface.
