Siemens SIMATIC ET 200SP User Manual

Technical data
10.7 Module data
CPU 1515SP PC (F)
124 Manual, 05/2017, A5E32701806-AC
6ES7677-2AA41-0FB0
Ambient temperature during storage / transport
Min.
-40 °C
Max.
70 °C
I/O / Options
I/O
•
SD card
optional for additional mass storage
Dimensions
Width
160 mm
Height
117 mm
Depth
75 mm
Weights
Weight, approx.
0.83 kg
10.7.5
CPU 1515SP PC F, system version WES7 P 64Bit 4GB RAM
CPU 1515SP PC F, system version WES7 P 64Bit 4GB RAM
6ES7677-2FA41-0FB0
General information
Product type designation
CPU 1515SP PC
HW release number
FS02
Firmware version
V2.1
Engineering with
STEP 7 TIA Portal can be configured/integrated as of version
V14 SP1
PC configuration
Processor
Dual-Core 1 GHz, AMD G Series APU T40E
Main memory
4 GB RAM
Flash disk
30 GB
Operating systems
Windows Embedded Standard 7 P 64 bit
Installed SW
Visualization
No
Controller
S7-1500 Software Controller CPU 1505SP F
Operator controls
Mode selector
1
Supply voltage
Type of supply voltage
24 V DC
Low limit of permitted range (DC)
19.2 V
High limit of permitted range (DC)
28.8 V
Reverse polarity protection
Yes

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
