Siemens SIMATIC ET 200SP User Manual

Technical data
10.7 Module data
CPU 1515SP PC (F)
Manual, 05/2017, A5E32701806-AC
125
6ES7677-2FA41-0FB0
Power and voltage failure backup
Power/voltage failure backup time
5 ms
Input current
Current consumption (rated value)
1.5 A; full processor load, incl. ET 200SP modules and USB
use
Current consumption (in no-load operation), typ.
0.6 A
Inrush current, max.
4.7 A; rated value
Power
Power consumption, max.
36 W; incl. ET 200SP modules and USB use
Incoming power to the backplane bus
8.75 W
Power loss
Power loss, typ.
15 W; without ET 200SP modules and without USB use
Memory
Type of memory
DDR3-SDRAM
CFast memory card
Yes; 30 GB flash memory
SIMATIC memory card required
No
Work memory
Integrated (for program)
1.5 MB
Integrated (for data)
5 MB
Integrated (for ODK application)
10 MB
Load memory
Integrated (on PC mass storage medium)
320 MB
Buffering
with UPS
Yes; all retentive declared memory areas
with non-volatile memory
Yes
Hardware configuration
integrated power supply
Yes
Number of DP masters
Via CM
1
Racks
Modules per rack, max.
64; CPU 1515SP PC + 64 module + server module
Number of rows, max.
1
Time-of-day
Clock
Type
Hardware clock
Buffering time
6 wk; at 40 °C ambient temperature, typ.
Deviation per day, max.
10 s; typ.: 2 s

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
