Siemens SIMATIC ET 200SP User Manual

Product overview
3.3 Sample configuration
CPU 1515SP PC (F)
Manual, 05/2017, A5E32701806-AC
21
System versions and ordering options
System version
SIMATIC software
CFast card
Article number
WES7 E 32Bit
CPU 1505SP V2.1
30 GB
6ES7677-2AA31-0EB0
WES7 P 64Bit
(multitouch functionality)
CPU 1505SP V2.1 30 GB 6ES7677-2AA41-0FB0
CPU 1505SP V2.1 & WinCC Runtime
Adv. V14 SP1 128PT
30 GB 6ES7677-2AA41-0FK0
CPU 1505SP V2.1 & WinCC Runtime
Adv. V14 SP1 512PT
30 GB 6ES7677-2AA41-0FL0
CPU 1505SP V2.1 & WinCC Runtime
Adv. V14 SP1 2048PT
30 GB 6ES7677-2AA41-0FM0
WES7 E 32Bit
CPU 1505SP F V2.1
30 GB
6ES7677-2FA31-0EB0
WES7 P 64Bit
(multitouch functionality)
CPU 1505SP F V2.1
30 GB
6ES7677-2FA41-0FB0
CPU 1505SP F V2.1 & WinCC
Runtime Adv. V14 SP1 128PT
30 GB 6ES7677-2FA41-0FK0
CPU 1505SP F V2.1 & WinCC
Runtime Adv. V14 SP1 512PT
30 GB 6ES7677-2FA41-0FL0
CPU 1505SP F V2.1 & WinCC
Runtime Adv. V14 SP1 2048PT
30 GB 6ES7677-2FA41-0FM0
CPU 1515SP PC, spare part, without CFast card, without software
6ES7677-2AA40-0AA0
3.3
Sample configuration
Configuration
CPU 1515SP PC (F) is mounted on the mounting rail according to EN 60715. A modular
system is formed with ET 200SP modules in the central rack.
You can use the CPU 1515SP PC (F) as PROFINET IO controller. The PROFINET IO
devices are connected with the SIMATIC BusAdapter BA 2xRJ45 via the ports of the
interface X1 PN (LAN).
Devices can be connected via Industrial Ethernet using the integrated interface
X2 PN/IE (LAN).
The connection to PROFIBUS can be made using the DP master module.

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
