Siemens SIMATIC ET 200SP User Manual

Technical data
10.7 Module data
CPU 1515SP PC (F)
Manual, 05/2017, A5E32701806-AC
123
6ES7677-2AA41-0FB0
Video interfaces
Graphics interface
1x DVI-I
1st interface
Interface hardware
Number of ports
2
integrated switch
Yes
RJ 45 (Ethernet)
Yes; via BusAdapter BA 2x RJ45
•
Transmission rate, max.
100 Mbps
•
Industrial Ethernet status LED
Yes
2nd interface
Interface hardware
Number of ports
1
RJ 45 (Ethernet)
Yes; integrated
•
Transmission rate, max.
1000 Mbps
•
Industrial Ethernet status LED
No
3rd interface
Interface hardware
RS 485
Yes
Interface hardware
RJ 45 (Ethernet)
100 Mbps
Yes; for 1st Interface X1
1000 Mbps
Yes; for 2nd Interface X2
Autonegotiation
Yes
Autocrossing
Yes
RS 485
Transmission rate, max.
12 Mbps
Interrupts/diagnostics/status information
LED diagnostics display
RUN/STOP LED
Yes
ERROR LED
Yes
MAINT LED
Yes
Ambient conditions
Ambient temperature in operation
Min.
0 °C
Max.
Up to 60 °C with max. 32 ET 200SP modules and
3x 100 mA USB load; up to 55 °C with max 64 ET 200SP
modules and 2x max. 500 mA and 1x max. 100 mA USB
load
Horizontal installation, min.
0 °C
Horizontal installation, max.
60 °C
Vertical installation, min.
0 °C
Vertical installation, max.
50 °C; with max. 32 ET 200SP modules and 3x 100 mA
USB load

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
