Installing
4.1 Basics
CPU 1515SP PC (F)
Manual, 05/2017, A5E32701806-AC
35
Mounting rail
CPU 1515SP PC (F) is mounted on a mounting rail according to EN 60715 (35 × 7.5 mm
and/or 35 × 15 mm).
You must ground the mounting rail separately in the control cabinet. Exception: If you install
the rail on grounded, zinc-plated mounting plates, there is no need to ground the rail
separately.
Note
If the ET 200SP distributed I/O system is exposed to vibration and shock loads, both ends of
the ET 200SP system assembly must be mechanically fixed to the mounting rail (e.g using
8WA1010
-1PH01 ground terminals). This measure prevents the ET 200SP from shifting to
the side.
Note
If the ET 200SP distributed I/O system is exposed to high vibration and shock load, we
recommend that you screw the mounting rail to the mounting surface at interval
s of approx.
200 mm.
Suitable surface finishes are:
● Steel strip in accordance with Appendix A of EN 60715 or
● Tinned steel strip. We recommend the use of the mounting rails in section
Accessories/spare parts (Page 133).
Note
Mounting rails of other manufacturers
If you use mounting rails from other manufacturers, ensure that they have the properties
required for your climatic and mechanical a
mbient conditions.
Check whether the mounting rails meet the requirements for a protective conductor.

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
