Technical data
10.7 Module data
CPU 1515SP PC (F)
Manual, 05/2017, A5E32701806-AC
113
6ES7677-2AA31-0EB0
Memory
Type of memory
DDR3-SDRAM
CFast memory card
Yes; 30 GB flash memory
SIMATIC memory card required
No
Work memory
Integrated (for program)
1 MB
Integrated (for data)
5 MB
Integrated (for ODK application)
10 MB
Load memory
Integrated (on PC mass storage medium)
320 MB
Buffering
with UPS
Yes; all retentive declared memory areas
with non-volatile memory
Yes
Hardware configuration
integrated power supply
Yes
Number of DP masters
Via CM
1
Racks
Modules per rack, max.
64; CPU 1515SP PC + 64 module + server module
Number of rows, max.
1
Time-of-day
Clock
Type
Hardware clock
Buffering time
6 wk; at 40 °C ambient temperature, typ.
Deviation per day, max.
10 s; typ.: 2 s
Interfaces
Number of Industrial Ethernet interfaces
2
Number of PROFINET interfaces
1
Number of PROFIBUS interfaces
1
Number of interfaces RS 485
1; via CM DP module
Number of USB interfaces
3; 3x USB 2.0 front, 500 mA each – of which 2 x 500 mA
and 1 x 100 mA simultaneously
Number of SD card slots
1
Video interfaces
Graphic interface
1x DVI-I
1st interface
Interface hardware
Number of ports
2
Integrated switch
Yes
RJ 45 (Ethernet)
Yes; via BusAdapter BA 2x RJ45
•
Transmission rate, max.
100 Mbps
•
Industrial Ethernet status LED
Yes

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
