Technical data
10.7 Module data
CPU 1515SP PC (F)
128 Manual, 05/2017, A5E32701806-AC
6ES7677-2AA40-0AA0
Operator controls
Mode selector
1
Supply voltage
Type of supply voltage
24 V DC
Low limit of permitted range (DC)
19.2 V
High limit of permitted range (DC)
28.8 V
Reverse polarity protection
Yes
Power and voltage failure backup
Power/voltage failure backup time
5 ms
Input current
Current consumption (rated value)
1.5 A; full processor load, incl. ET 200SP modules and USB
use
Current consumption (in no-load operation), typ.
0.6 A
Inrush current, max.
4.7 A; rated value
Power
Power consumption, max.
36 W; incl. ET 200SP modules and USB use
Incoming power to the backplane bus
8.75 W
Power loss
Power loss, typ.
15 W; without ET 200SP modules and without USB use
Memory
Type of memory
DDR3-SDRAM
CFast memory card
No
Work memory
Integrated
4 GB
Hardware configuration
integrated power supply
Yes
Number of DP masters
Via CM
1
Racks
Modules per rack, max.
64; CPU + 64 Module + server module (mounting width
max. 1 m)
Number of rows, max.
1
Time-of-day
Clock
Type
Hardware clock
Buffering time
6 wk; at 40 °C ambient temperature, typ.
Deviation per day, max.
10 s; typ.: 2 s
Interfaces
Number of Industrial Ethernet interfaces
2
Number of PROFINET interfaces
1
Number of PROFIBUS interfaces
1; via CM DP module
Number of interfaces RS 485
1; via CM DP module
Number of USB interfaces
3; 3x USB 2.0 front, 500 mA each – of which 2 x 500 mA
and 1 x 100 mA simultaneously
