Operator control and monitoring
9.2 Working with the user interface
SIMATIC MV420 / SIMATIC MV440
196 Operating Instructions, 04/2013, A5E02371045-06
Achieving reproducible results
To obtain reproducible results:
● You must make sure during the commissioning of the reader that the device can be
operated without being influenced by changes in the brightness of the surroundings, for
example due to shielding.
● The setup must be implemented according to the requirements of the standard being
applied.
● Ensure that the resolution is correct (> 10 pixels with DMC).
● The complete code must be sharply imaged.
● No dirt on the lens or on the chip.
Note
Detailed description of parameters in the online help
For a detailed description of the parameters and possible values, refer to the online help.
"Save" tab
Figure 9-27 Verification library – "Save" tab
