Operator control and monitoring
9.2 Working with the user interface
SIMATIC MV420 / SIMATIC MV440
Operating Instructions, 04/2013, A5E02371045-06
197
"Name" input field
Specify the name under which the current verification will be saved. The entry is optional.
Possible values: Letters, numbers and underscores. Maximum of 10 characters.
"Number" input field
Specify the number with which you want to save the verification.
Value range: 1 to 5
"Save now" button
Clicking on this button saves the current verification under the name specified
"Discard changes" button
This button discards the changes made since the verification was last saved.
If the verification is new and has not yet been saved, it will not be saved and will be lost.
Note
Detailed description of parameters in the online help
For a detailed description of the parameters and possible values, refer to the online help.
