Dimension drawings
SIMATIC MV420 / SIMATIC MV440
362 Operating Instructions, 04/2013, A5E02371045-06
SIMATIC MV420 reader









① Swivel lens and lamp protection ③ Ethernet socket
② LED displays ④ Power IO RS-232 socket
Figure 14-2 Dimension drawing: SIMATIC MV420 reader
