Dimension drawings
SIMATIC MV420 / SIMATIC MV440
Operating Instructions, 04/2013, A5E02371045-06
363
SIMATIC MV440 with lighting unit and mounting plate
① Ring light holder (external) ⑤ Reader
② Lighting unit SIMATIC Vision Sensor
VS100
⑥ Torx screws M4x8
③ Socket for lighting unit ⑦ Reader mounting plate
④ IP65 protective lens cover ∅ 50
Figure 14-3 Dimension drawing: SIMATIC MV440 with attached lighting unit and mounting plate
