Instructions
9.3 PID_Temp
PID control
376 Function Manual, 03/2017, A5E35300227-AC
New features of PID_Temp
PID_Temp V1.1
●
Response of the output value on switchover from "Inactive" operating mode to "Automatic
mode"
The new option IntegralResetMode = 4 was added and defined as default. With
IntegralResetMode = 4, the integral action is automatically pre-assigned when switching
from "Inactive" operating mode to "Automatic mode" so that a control deviation results in
a jump of the PID output value with identical sign.
●
Initialization of the integral action in automatic mode
The integral action can be initialized in automatic mode with the tags
OverwriteInitialOutputValue and PIDCtrl.PIDInit. This simplifies the use of PID_Temp for
override controls.
Compatibility with CPU and FW
The following table shows which version of PID_Temp can be used on which CPU.
S7-1200 V4.2 or higher V1.1
V4.1 V1.0
S7-1500 V2.0 or higher V1.1
