Configuring a software controller
3.10 Parameter view
PID control
62 Function Manual, 03/2017, A5E35300227-AC
Status of configuration (offline)
The status of the configuration is indicated by icons:
● In the “Status of configuration” column in the parameter table
● In the navigation structure of the functional navigation and data navigation
Symbol in “Status of configuration” column
The start value of the parameter corresponds to the default value and is valid. A start value has not yet
been defined by the user.
The start value of the parameter contains a value defined by the user or an automatically adjusted value.
The start value is different than the default value. The start value is error-free and valid.
The start value of the parameter is invalid (syntax or process-related error).
The input box has a red background. When clicked, the roll-out error message indicates the cause of the
Only for S7-1200 Motion Control:
The start value of the parameter is valid but contains warnings.
The input box has a yellow background.
The parameter is not relevant in the current configuration.
The symbols in the navigation indicate the progress of the configuration in the same way as
in the configuration dialog of the technology object.
Configure technology objects (Page 42)
