Configuring a software controller
3.10 Parameter view
PID control
Function Manual, 03/2017, A5E35300227-AC
51
3.10.2
Structure of the parameter view
3.10.2.1
Toolbar
The following functions can be selected in the toolbar of the parameter view.
Icon
Function
Explanation
Monitor all Starts the monitoring of visible parameters in the active Parameter
view (online mode).
Create snapshot of
monitor values and
accept setpoints of this
snapshot as start values
Applies the current monitor values to the “Snapshot” column and
updates the start values in the project.
Only in online mode for PID_Compact, PID_3Step and PID_Temp.
Initialize setpoints Transfers the start values updated in the project to the CPU.
Only in online mode for PID_Compact, PID_3Step and PID_Temp.
Create snapshot of
monitor values
Applies the current monitor values to the “Snapshot” column.
Only in online mode.
Modify all selected pa-
rameters immediately
and once
This command is executed once and as quickly as possible without
reference to any particular point in the user program.
Only in online mode.
Select navigation struc-
ture
Toggles between functional navigation and data navigation.
Text filter... After entry of a character string: Display of all parameters containing
the specified string in one of the currently visible columns.
Selection of compare
values
Selection of parameter values that are to be compared with one
another in online mode (Start value project, Start value PLC, Snap-
shot)
Only in online mode.
Save window settings Saves your display settings for the Parameter view (e.g., selected
navigation structure, activated table columns, etc.)
