Using PID_Compact
4.2 PID_Compact V2
PID control
Function Manual, 03/2017, A5E35300227-AC
89
To perform fine tuning, follow these steps:
1. Select the entry "Fine tuning" in the "Tuning mode" drop-down list.
2. Click the "Start" icon.
– An online connection will be established.
– Value recording is started.
– The process of fine tuning is started.
– The "Status" field displays the current steps and any errors that may have occurred.
The progress bar indicates the progress of the current step.
Note
Click the "Stop" icon in the "Tuning mode" group when the progress bar has reached
100% and it is to be assumed that tuning is blocked. Check the configuration of the
technology object and, if necessary,
restart controller tuning.
If no errors occurred during fine tuning, the PID parameters have been tuned. PID_Compact
switches to automatic mode and uses the tuned parameters. The tuned PID parameters will
be retained during power OFF and a restart of the CPU.
If errors occurred during "fine tuning", PID_Compact responds with the configured response
to errors.
Parameters State and Mode V2 (Page 265)
