Data sheet of 1FN3100-4NC80-0xAx
1FN3100-4NC80-0xAx
Technical data
Designation
Unit
Value
General conditions
DC-link voltage
U
DC
V
600
Water cooling flow temperature
T
VORL
°C
35
Rated temperature
T
N
°C
120
Data at the rated point
Rated force
F
N
N
1210
Rated current
I
N
A
15.9
Maximum velocity at rated force
v
MAX,FN
m/min
296
Rated power loss
P
V,N
kW
1
Limit data
Maximum force
F
MAX
N
2040
Maximum current
I
MAX
A
33.1
Maximum velocity at maximum force
v
MAX,FMAX
m/min
162
Maximum electric power drawn
P
EL,MAX
kW
9.83
Static force
F
0
*
N
867
Stall current
I
0
*
A
11.3
Physical constants
Force constant at 20 °C
k
F,20
N/A
77.1
Voltage constant
k
E
Vs/m
25.7
Motor constant at 20 °C
k
M,20
N/W
0.5
45.8
Motor winding resistance at 20 °C R
STR,20
Ω 0.947
Phase inductance L
STR
mH 11.5
Attraction force F
A
N 3970
Thermal time constant t
TH
s 180
Pole width
τ
M
mm
15
Mass of the primary section
m
P
kg
9.9
Mass of the primary section with precision cooler m
P,P
kg 11.2
Mass of a secondary section
m
S
kg
0.7
Mass of a secondary section with heatsink profiles
m
S,P
kg
0.8
Primary section main cooler data
Maximum dissipated thermal output
Q
P,H,MAX
kW
0.889
Recommended minimum volume flow rate
V
P,H,MIN
l/min
2.5
Coolant temperature rise
ΔT
P,H
K
5.11
Pressure drop
Δp
P,H
bar
1.95
Primary section precision cooler data
Maximum dissipated thermal output
Q
P,P,MAX
kW
0.0263
Recommended minimum volume flow rate
V
P,P,MIN
l/min
2.5
Pressure drop
Δp
P,P
bar
0.167
