9.3 1FN3050, 1FN3100, 1FN3150
1FN3 linear motors
516 Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
Dimensions of the peak load primary section 1FN3050
Size
Variable
Unit
1FN3050-...
1W
2W
3W
4W
5W
Length
lP
mm
255
Longitudinal hole pattern
lP1
mm
52.5
Total longitudinal hole pattern
lP2
mm
157.5
Position 1st hole longitudinal pattern
lP3
mm
63
Position of the magnetically active surface
lP4
mm
247
Magnetically active length
lP,AKT
mm
210
Main cooler connector position (width)
bHK
mm
55
Width without precision cooler
bP
mm
67
Transverse hole pattern
bP1
mm
30
Total transverse hole pattern
bP2
mm
–
Precision cooler connector spacing
bPK
mm
17
Precision cooler width
bPK1
mm
76
Precision cooler connection position
bPK2
mm
68
Main cooler connection spacing
hHK
mm
17
Main cooler connection position (height)
hHK1
mm
26.4
Motor height with additional coolers
hM1
mm
63.4
Motor height with precision cooler
hM2
mm
60.4
Motor height without additional cooler
hM3
mm
48.5
Motor height with heatsink profile without
precision cooler
hM4 mm 51.5
Height of primary section without precision
cooler
hP1 mm 35.8
Height of primary section with precision cooler hP2 mm 47.7
Precision cooler height hPK mm 11.9
Precision cooler connector position (height)
hPK1
mm
6
Mounting screw thread
MP
M5
Version with one connecting cable (end of the Article No. ...0HA1)
Cable 1 position (width)
bL1
mm
24.5
Cable 1 position (height)
hL1
mm
17.9
Version with 2 connecting cables (end of the Article No. ...0EA1 bzw 0FA1)
Power cable position L1 (width)
bL1
mm
16
Power cable position L1 (height)
hL1
mm
11.9
Signal cable position L2 (width)
bL2
mm
33
Signal cable position L2 (height)
hL2
mm
23.9
