Siemens SIMOTICS L-1FN3 Configuration Manual

Description of the motor
2.5 Selection and ordering data
1FN3 linear motors
Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
55
Article No. Primary section
F
N
in N
F
MAX
in N
I
N
in A
I
MAX
in A
v
MAX,FN
in m/min
v
MAX,FMAX
in m/min
P
V,N
in kW
1FN3600-4NB80-0xAx
6920
11700
56.7
119
195
108
3.74
1FN3900-2NB20-0xAx
5190
8810
28.4
59.6
128
69.4
2.65
1FN3900-2NC80-0xAx
5190
8810
64.2
135
304
170
2.89
1FN3900-3NB20-0xAx
7780
13200
42.5
89.5
127
68.9
3.97
1FN3900-4NA50-0xAx
10400
17600
29.3
61.6
59.4
28.2
5.26
1FN3900-4NA80-0xAx
10400
17600
40.8
85.8
87.9
45.6
5.28
1FN3900-4NB20-0xAx
10400
17600
56.7
119
127
68.6
5.29
F
N
= rated force,
F
MAX
= maximum force,
I
N
= rated current,
I
MAX
= maximum current,
v
MAX,FN
= maximum velocity at rated
force, v
MAX,FMAX
= maximum velocity at maximum force, P
V,N
= power loss at the rated point
Table 2- 14 Overview of the most important data of the continuous load motors of the 1FN3 product family / Part 2
Article No. Primary section
h
M3
/ h
M1
in mm
b
P
/ b
PK1
in mm
l
P
in mm
l
P,AKT
in mm
m
P
/ m
P,P
in kg
l
S
in mm
m
S
/ m
S,P
in kg
1FN3050-1ND00-0xAx
59.4 / 74.3
67 / 76
162
117
2.2 / 2.69
120
0.4 / 0.5
1FN3050-2NB80-0xAx
59.4 / 74.3
67 / 76
267
222
3.9 / 4.6
120
0.4 / 0.5
1FN3050-2NE00-0xAx
59.4 / 74.3
67 / 76
267
222
3.9 / 4.6
120
0.4 / 0.5
1FN3100-1NC00-0xAx
59.4 / 74.3
96 / 105
162
117
3 / 3.52
120
0.7 / 0.8
1FN3100-2NC80-0xAx
59.4 / 74.3
96 / 105
267
222
5.4 / 6.19
120
0.7 / 0.8
1FN3100-3NA80-0xAx
59.4 / 74.3
96 / 105
372
327
7.5 / 8.56
120
0.7 / 0.8
1FN3100-3NC00-0xAx
59.4 / 74.3
96 / 105
372
327
7.5 / 8.56
120
0.7 / 0.8
1FN3100-4NC80-0xAx
59.4 / 74.3
96 / 105
477
432
9.9 / 11.2
120
0.7 / 0.8
1FN3150-1NC20-0xAx
61.4 / 76.3
126 / 135
162
117
4 / 4.5
120
1.2 / 1.3
1FN3150-2NB80-0xAx
61.4 / 76.3
126 / 135
267
222
7.3 / 8.15
120
1.2 / 1.3
1FN3150-3NB80-0xAx
61.4 / 76.3
126 / 135
372
327
10.5 / 11.7
120
1.2 / 1.3
1FN3150-3NC70-0xAx 61.4 / 76.3 126 / 135 372 327 10.5 / 11.7 120 1.2 / 1.3
1FN3150-4NB80-0xAx 61.4 / 76.3 126 / 135 477 432 13.9 / 15.3 120 1.2 / 1.3
1FN3300-1NC10-0xAx 78 / 92.9 141 / 151 238 179 8.8 / 9.51 184 2.4 / 2.6
1FN3300-2NC10-0xAx 78 / 92.9 141 / 151 399 340 15.9 / 17 184 2.4 / 2.6
1FN3300-2NH00-0xAx
78 / 92.9
141 / 151
399
340
15.9 / 17
184
2.4 / 2.6
1FN3300-3NB50-0xAx
78 / 92.9
141 / 151
560
501
23 / 24.4
184
2.4 / 2.6
1FN3300-3NC40-0xAx 78 / 92.9 141 / 151 560 501 23 / 24.4 184 2.4 / 2.6
1FN3300-4NB80-0xAx
78 / 92.9
141 / 151
721
662
29.9 / 31.8
184
2.4 / 2.6
1FN3450-1NB50-0xAx
80 / 94.9
188 / 197
238
179
12 / 12.8
184
3.8 / 4
1FN3450-2NB40-0xAx
80 / 94.9
188 / 197
399
340
22.5 / 23.7
184
3.8 / 4
1FN3450-2NB80-0xAx
80 / 94.9
188 / 197
399
340
22.5 / 23.7
184
3.8 / 4
1FN3450-2NC50-0xAx
80 / 94.9
188 / 197
399
340
22.5 / 23.7
184
3.8 / 4
1FN3450-3NA50-0xAx
80 / 94.9
188 / 197
560
501
32.7 / 34.3
184
3.8 / 4
1FN3450-3NB50-0xAx
80 / 94.9
188 / 197
560
501
32.7 / 34.3
184
3.8 / 4
1FN3450-3NC50-0xAx
80 / 94.9
188 / 197
560
501
32.7 / 34.3
184
3.8 / 4
