Siemens SIMOTICS L-1FN3 Configuration Manual

Description of the motor
2.5 Selection and ordering data
1FN3 linear motors
56 Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
Article No. Primary section
h
M3
/ h
M1
in mm
b
P
/ b
PK1
in mm
l
P
in mm
l
P,AKT
in mm
m
P
/ m
P,P
in kg
l
S
in mm
m
S
/ m
S,P
in kg
1FN3450-4NB20-0xAx
80 / 94.9
188 / 197
721
662
42 / 44
184
3.8 / 4
1FN3450-4NB80-0xAx
80 / 94.9
188 / 197
721
662
42 / 44
184
3.8 / 4
1FN3600-2NB00-0xAx
78 / 99.9
248 / 257
399
340
30.4 / 32
184
4.6 / 5
1FN3600-2NB80-0xAx
78 / 99.9
248 / 257
399
340
30.4 / 32
184
4.6 / 5
1FN3600-2NE50-0xAx
78 / 99.9
248 / 257
399
340
30.4 / 32
184
4.6 / 5
1FN3600-3NB00-0xAx
78 / 99.9
248 / 257
560
501
44.3 / 46.4
184
4.6 / 5
1FN3600-3NB80-0xAx
78 / 99.9
248 / 257
560
501
44.3 / 46.4
184
4.6 / 5
1FN3600-4NA70-0xAx
78 / 99.9
248 / 257
721
662
58.2 / 60.8
184
4.6 / 5
1FN3600-4NB80-0xAx
78 / 99.9
248 / 257
721
662
58.2 / 60.8
184
4.6 / 5
1FN3900-2NB20-0xAx
80 / 102
342 / 351
399
340
43.5 / 45.3
184
7.5 / 7.9
1FN3900-2NC80-0xAx
80 / 102
342 / 351
399
340
43.5 / 45.3
184
7.5 / 7.9
1FN3900-3NB20-0xAx
80 / 102
342 / 351
560
501
63 / 65.5
184
7.5 / 7.9
1FN3900-4NA50-0xAx
80 / 102
342 / 351
721
662
82 / 85.1
184
7.5 / 7.9
1FN3900-4NA80-0xAx
80 / 102
342 / 351
721
662
82 / 85.1
184
7.5 / 7.9
1FN3900-4NB20-0xAx
80 / 102
342 / 351
721
662
82 / 85.1
184
7.5 / 7.9
h
M3
= motor height without additional heatsinks,
h
M1
= motor height with additional heatsinks,
b
P
=
motor width without
prec
ision cooler,
b
PK1
= motor width with precision cooler,
l
P
= length of the primary section (without connection cover),
l
P,AKT
= magnetically active length of the primary section,
m
P
= weight of the primary primary section,
m
P,P
= weight of the
primary section with precision co
oler,
l
S
= length of the secondary section,
m
S
= weight of the secondary section,
m
S,P
= weight of the secondary section with heatsink profiles
