Siemens SINAMICS S120 - Options

Cabinet Modules
5.3 Smart Line Modules
Cabinet Modules NEMA
176 Manual, 04/2014, A5E03586450A
5.3.3
Options
Note
Additional information
The indi
vidual options are described in the section "Options".
Electrical options
Component
Option
CBC10 Communication Board
G20
CBE20 Communication Board
G33
Contactor monitoring
G56
AOP30 operator panel
K08
Control Unit CU320-2 PROFIBUS
K90
Performance extension for CU320-2
K94
Control Unit CU320-2 PROFINET
K95
Line reactor not included in product package
L22
Cabinet anti-condensation heating
L55
50/250 kW braking unit
L62/L65
Mechanical options
Component
Option
Base (plinth) 4" (100 mm) high, RAL 7022
M06
Cable marshalling compartment 8" (200 mm) high, RAL 7035
M07
Degree of protection IP21
M21
Degree of protection IP23 (NEMA1 filtered) / IP43 / IP54
(NEMA12 ventilated)
M23, M43, M54
Side panel (right)
M26
Side panel (left)
M27
Closed cabinet door (air inlet from below through floor opening)
M59
Additional shock protection M60
DC busbar system
M80 ... M87
Crane transport aid (top-mounted)
M90
Other options
Component
Option
UL listing per UL 508A
U90
cUL listing for Canada per UL 508A
U91
