Electrical installation
4.5 Connections
Cabinet Modules NEMA
104 Manual, 04/2014, A5E03586450A
Safety and EMC
WARNING
Risk of death due to hazardous voltage when covers are missing
If covers are missing, live parts may be touched, which may result in death or serious
injury.
• Re-install all covers that you have removed for feeding in cables before putting the
Cabinet Module into operation.
Note
Internal cabinet wiring
It must be ensured when laying cables that existing wiring inside the cabinet is not changed.
Note
EMC-compliant shielding
In order to achieve EMC
-compliant shielding, the shield plates must be reattached before
putting the ca
binet into operation.
The shields of the motor cables must be attached to the EMC shield bar (option M70), and
the PE cables to the PE bar.
4.5.12.2
Cable routing for Line Connection Modules
For the Line Connection Modules, the customer must carry out the following cabling or
connection work:
Table 4- 14 Checklist for cabling or connection work for Line Connection Modules
Cable routing
Completed?
Cable for the line supply (L1, L2, L3, PE)
Signal cables
Note:
The "Basic rules for cable routing" and "Preparatory steps" described above must
be observed whenever any cabling or connection work is performed.
