8.31 L45, EMERGENCY OFF pushbutton installed in the cabinet door
Cabinet Modules NEMA
458 Manual, 04/2014, A5E03586450A
8.31
L45, EMERGENCY OFF pushbutton installed in the cabinet door
Availability of option
This option is available for the following S120 Cabinet Modules:
● Line Connection Modules
Description
The EMERGENCY OFF pushbutton with protective collar is integrated in the cabinet door of
the Line Connection Module. The contacts of the pushbutton are connected to a terminal
block. From here, the EMERGENCY OFF pushbutton can be integrated into the plant-side
EMERGENCY OFF chain.
Note
Ensure EMERGENCY OFF function on the plant side
The EMERGENCY OFF function must be ensured on the plant side.
X120 checkback contact "EMERGENCY OFF pushbutton in the cabinet door"
Table 8- 49 Terminal block X120
Terminal
Designation
1)
Technical specifications
1
NC Checkback contacts of EMERGENCY OFF pushbutton in the
cabinet door
max. load current: 10 A
Max. switching voltage: 250 V AC
Max. switching capacity: 250 VA
Required minimum load: ≥ 1 mA
2
3
NC (internal)
4
Max. connectable cross-section #12 AWG (4 mm²)
1)
NC: NC contact
