8.41 M51, Motor reactor terminal connection
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
489
8.41
M51, Motor reactor terminal connection
Availability of option
This option is available for the following S120 Cabinet Modules:
● Booksize Cabinet Kits
Description
In connection with option M77 (version without component support plates and without
additional control components), option L08/L09 (motor reactor / 2 motor reactors in series)
allows the motor cables to be connected directly to the motor reactor.
With option M51, the connection of the motor cable is wired to a customer connection
terminal -X1.
Table 8- 63 Maximum conductor cross-section when using motor reactors for Booksize Cabinet Kits
Order no.
6SL3720-
Power in kW (HP)
Maximum conductor cross-
section in mm² (AWG)
1TE21-0AB3
4.8 (5)
6 (10)
1TE21-8AB3
9.7 (10)
6 (10)
1TE23-0AB3
16 (20)
6 (10)
1TE24-5AB3 24 (30) 16 (6)
1TE26-0AB3
32 (40)
16 (6)
1TE28-5AB3
46 (60)
35 (2)
1TE31-3AB3
71 (100)
95 (4/0)
