Siemens SINAMICS S120 - Smart Line Modules; Description

Cabinet Modules
5.3 Smart Line Modules
Cabinet Modules NEMA
166 Manual, 04/2014, A5E03586450A
5.3
Smart Line Modules
5.3.1
Description
Note
Additional information
Refer to the layout diagrams (AO) and circuit diagrams (SP) provided on the customer DVD
supplied with the device for the arrangement of components and interfaces, and for wiring.
Figure 5-18 Smart Line Module
