Options
8.42 M59, closed cabinet door, air inlet from below through floor opening
Cabinet Modules NEMA
490 Manual, 04/2014, A5E03586450A
M59, closed cabinet door, air inlet from below through floor opening
Availability of option
This option is available for the following S120 Cabinet Modules:
● Line Connection Modules
● Basic Line Modules
● Smart Line Modules
● Active Line Modules
● Booksize base cabinets
● Motor Modules in chassis format
● Auxiliary Power Supply Modules
The standard cabinet units are supplied with integrated ventilation grills in the bottom of the
doors as standard.
With option M59, the Cabinet Modules are delivered with closed doors.
Note
When closed doors are used, the base plates, which are available as standard for ensuring a
sufficient cooling air supply, are not required.
In this case, the customer must ensure that no dirt/conductive dust or moisture can enter the
Cabinet Module. Cables must not be routed in such a way that they impede the flow of
air
through the cabinet floor opening.
If the area beneath the Cabinet Modules can be accessed, the customer must provide shock
protection.
The required ambient conditions must be taken into account to prevent, for example,
overheating of the cabinet and
the ingress of dirt or moisture.
When removing doors, take care not to damage the grounding strips attached to them. Make
sure that the strips are reattached properly when the doors are installed.
Note
Opening angle of the door
The door opening angle
with free-standing cabinet units is 180 °.
-by-side configuration of the cabinet units, this opening angle is 130 °.
For degrees of protection IP23 (NEMA1 filtered) / IP43 / IP54 (NEMA12 ventilated) and with
option L37 (DC interface including pr
e-charging input circuit), the door opening angle is only
.
