Cabinet Modules
5.3 Smart Line Modules
Cabinet Modules NEMA
178 Manual, 04/2014, A5E03586450A
Order no.
6SL3730-
6TE35-
5AU3
6TE37-
3AU3
6TE41-
1AU3
6TE41-
3AU3
6TE41-
7AU3
Weight
(standard model) lb
kg
596
270
596
270
1080
490
1709
775
1709
775
Frame size
GX GX HX JX JX
SCCR (short circuit current rating)
kA IC
65
65
84
84
100
Minimum short-circuit current
6)
A
6200
9200
2000
2500
3200
1)
The base load current I
H DC
is based on a duty cycle of 150 % for 60 s or I
max DC
for 5 s with a duty cycle duration of
300 s.
2)
The current demand for the 400 V AC auxiliary supply is provided by the supply input voltage.
3)
The specified power loss represents the maximum value at 100 % capacity utilization. The value in normal operation is
lower.
4)
Total of all motor cables and DC link. Longer cable lengths for specific configurations are available on request, see
SINAMICS - Low Voltage Configuration Manual on the customer DVD supplied with the device.
5)
The cabinet height increases by 10" (250 mm) with degree of protection IP21, and by 16" (400 mm) with degrees of
protection IP23 (NEMA1 filtered), IP43, and IP54 (NEMA12 ventilated).
6)
Minimum current required for reliable tripping of the contained protective devices.
