Cabinet Modules
5.6 Motor Modules in chassis format
Cabinet Modules NEMA
220 Manual, 04/2014, A5E03586450A
Note
Mixed operation is not possible
It is only possible to connect identical power units in parallel if both power units have the
same hardware version. Mi
xed operation between a power unit with Control Interface
Module and a power unit with Control Interface Board is not possible.
Minimum cable lengths for parallel connection and connection to a motor with a single-winding
system
Note
Minimum cable lengths
The minimum cable lengths specified in the table below must be observed when two or more
Motor Modules are connected in parallel and there is a connection to a motor with a single
-
winding sys
tem. The motor cables of Motor Modules connected in parallel may only be
connected with one another at the motor terminal box.
A motor reactor (option L08) must be used if the required cable length cannot be reached in
the application.
Table 5- 31 Motor Modules, 510 to 720 VDC
Order no.
Frame size
P
n
[HP] ([kW])
I
rated rms
[A]
Minimum length [ft] ([m])
6SL3720-1TE32-1AU3
FX
150 (110)
210
98 (30)
6SL3720-1TE32-6AU3
FX
200 (132)
260
89 (27)
6SL3720-1TE33-1AU3
GX
250 (160)
310
66 (20)
6SL3720-1TE33-8AU3
GX
300 (200)
380
56 (17)
6SL3720-1TE35-0AU3
GX
400 (250)
490
49 (15)
6SL3720-1TE36-1AU3
HX
500 (315)
605
43 (13)
6SL3720-1TE37-5AU3
HX
600 (400)
745
33 (10)
6SL3720-1TE38-4AU3
HX
700 (450)
840
29 (9)
6SL3720-1TE41-0AU3 JX 800 (560) 985 26 (8)
6SL3720-1TE41-2AU3
JX
1000 (710)
1260
20 (6)
6SL3720-1TE41-4AU3
JX
1150 (800)
1405
16 (5)
