Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
CANCELSUB P Cancel current subprogram level +/- +/- FM-SA
CASE K Conditional program branch +/- PM-NC
CDC K Direct approach of a position +/- PM-NC
CDOF
6)
G Switch off collision monitoring m +/- PM-NC
CDOF2 G Switch off collision monitoring during 3D cir‐
cumferential milling
m +/- PM-NC
CDON G Activate collision monitoring m +/- PM-NC
CFC
6)
G Constant feedrate on contour m +/- PM-NC
CFIN G Constant feedrate for internal radius only, not
for external radius
m +/- PM-NC
CFINE F Assignment of fine offset to a FRAME variable +/- - PM-NC
CFTCP G Constant feedrate in tool center point (center
point path)
m +/- PM-NC
CHAN K Specify validity range for data +/- PM-NC
CHANDATA P Set channel number for channel data access +/- - PM-NC
CHAR K Data type: ASCII character +/- PM-NC
CHF A Chamfer;
value = length of chamfer
s +/- PM-NC
CHKDM F Uniqueness check within a magazine +/- - FM-TM
CHKDNO F Check for unique D numbers +/- - PM-NC
CHR A Chamfer;
value = length of chamfer in direction of move‐
ment
+/- PM-NC
CIC K Approach position by increments +/- PM-NC
CIP G Circular interpolation through intermediate
point
m +/- PM-NC
CLEARM P Reset one/several markers for channel coor‐
dination
+/- +/- PM-NC
CLRINT P Deselect interrupt +/- - PM-NC
CMIRROR F Mirror on a coordinate axis +/- - PM-NC
COARSEA K Motion end when "Exact stop coarse" reached m +/- PM-NC
COLLPAIR F Check whether part of a collision pair +/- PM-NC
COMPCAD G Activate the compressor function COMPCAD m +/- PM-NC
COMPCURV G Activate the compressor function COMP‐
CURV
m +/- PM-NC
COMPLETE Control instruction for reading and writing data +/- PM-NC
COMPOF
6)
G Deactivate NC block compression m +/- PM-NC
COMPON G Activate the compressor function COMPON m +/- PM-NC
COMPSURF G Activate the compressor function COMPSURF m +/- PM-NC
CONTDCON P Activate tabular contour decoding +/- - PM-NC
CONTPRON P Activate reference preprocessing +/- - PM-NC
CORROF P All active overlaid movements are deselected. +/- - PM-NC
Tables
4.1 Operations
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1201
