Siemens SINUMERIK ONE MCP 2400.4c Programming Manual

Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
CORRTC F Modify offset vectors or direction vectors of
orientable tool carriers according to machine
measurement.
+/- - PM-NC
CORRTRAFO F Modifying offset vectors or direction vectors
for the orientation axes in the kinematic model
of the machine
+/- - PM-NC
COS F Cosine
(trigon. function)
+/- +/- PM-NC
COUPDEF P Definition ELG group/synchronous spindle
group
+/- - PM-NC
COUPDEL P Delete ELG group +/- - PM-NC
COUPOF P Deactivate ELG group / synchronous spindle
pair
+/- - PM-NC
COUPOFS P Deactivate ELG group/synchronous spindle
pair with stop of following spindle
+/- - PM-NC
COUPON P Activate ELG group / synchronous spindle pair +/- - PM-NC
COUPONC P Transfer activation of ELG group/synchro‐
nous spindle pair with previous programming
+/- - PM-NC
COUPRES P Reset ELG group +/- - PM-NC
CP
6)
G Path motion m +/- PM-NC
CPBC K Generic coupling: Block change criterion +/- +/- FM-A
CPDEF K Generic coupling: Creating a coupling module +/- +/- FM-A
CPDEL K Generic coupling: Deletion of a coupling mod‐
ule
+/- +/- FM-A
CPFMOF K Generic coupling: Behavior of the following
axis at complete switch-off
+/- +/- FM-A
CPFMON K Generic coupling: Behavior of the following
axis when switching on
+/- +/- FM-A
CPFMSON K Generic coupling: Synchronization mode +/- +/- FM-A
CPFPOS K Generic coupling: Synchronized position of
the following axis
+/- +/- FM-A
CPFRS K Generic coupling: Coordinate reference sys‐
tem
+/- +/- FM-A
CPLA K Generic coupling: Definition of a leading axis +/- - FM-A
CPLCTID K Generic coupling: Number of the curve table +/- +/- FM-A
CPLDEF K Generic coupling: Definition of a leading axis
and creation of a coupling module
+/- +/- FM-A
CPLDEL K Generic coupling: Deleting a leading axis of a
coupling module
+/- +/- FM-A
CPLDEN K Generic coupling: Denominator of the cou‐
pling factor
+/- +/- FM-A
CPLINSC K Generic coupling: Scaling factor of the input
value of a leading axis
+/- +/- FM-A
CPLINTR K Generic coupling: Offset value of the input val‐
ue of a leading axis
+/- +/- FM-A
Tables
4.1 Operations
NC programming
1202 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
