Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
CPLNUM K Generic coupling: Numerator of the coupling
factor
+/- +/- FM-A
CPLOF K Generic coupling: Switching off a leading axis
of a coupling module
+/- +/- FM-A
CPLON K Generic coupling: Switching on a leading axis
of a coupling module
+/- +/- FM-A
CPLOUTSC K Generic coupling: Scaling factor for the output
value of a coupling
+/- +/- FM-A
CPLOUTTR K Generic coupling: Offset value for the output
value of a coupling
+/- +/- FM-A
CPLPOS K Generic coupling: Synchronized position of
the leading axis
+/- +/- FM-A
CPLSETVAL K Generic coupling: Coupling reference +/- +/- FM-A
CPMALARM K Generic coupling: Suppression of special cou‐
pling-related alarm outputs
+/- +/- FM-A
CPMBRAKE K Generic coupling: Response of the following
axis to certain stop signals and stop com‐
mands
+/- - FM-A
CPMPRT K Generic coupling: Coupling response at part
program start under block search run via pro‐
gram test
+/- +/- FM-A
CPMRESET K Generic coupling: Coupling behavior for RE‐
SET
+/- +/- FM-A
CPMSTART K Generic coupling: Coupling behavior at part
program start
+/- +/- FM-A
CPMVDI K Generic coupling: Response of the following
axis to certain NC/PLC interface signals
+/- +/- FM-A
CPOF K Generic coupling: Switching off a coupling
module
+/- +/- FM-A
CPON K Generic coupling: Switching on a coupling
module
+/- +/- FM-A
CPRECOF
6)
G Deactivate programmable contour accuracy m +/- PM-NC
CPRECON G Activate programmable contour accuracy m +/- PM-NC
CPRES K Generic coupling: Activates the configured da‐
ta of the synchronous spindle coupling
+/- - FM-A
CPROT P Activate / deactivate channel-specific protec‐
tion zone
+/- - PM-NC
CPROTDEF P Definition of a channel-specific protection area +/- - PM-NC
CPSETTYPE K Generic coupling: Coupling type +/- +/- FM-A
CPSYNCOP K Generic coupling: Threshold value of position
synchronism "Coarse"
+/- +/- FM-A
CPSYNCOP2 K Generic coupling: Threshold value of position
synchronism "Coarse" 2
+/- +/- FM-A
CPSYNCOV K Generic coupling: Threshold value of velocity
synchronism "Coarse"
+/- +/- FM-A
Tables
4.1 Operations
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1203
