<Cntrl>: Controls the behavior of the function
Data type: INT
The <Cntrl> parameter is decimal coded (unit to thousands position):
Unit position: The unit position controls the response to errors.
xxx0 In the event of an error (return value < 0), alarm 14106 is
output and program processing is aborted.
Note:
The alarm is also output irrespective of the value of the unit
position when the <Cntrl> parameter is negative.
xxx1 In the event of an error (return value < 0) no alarm is output.
The user can react suitably in the program.
Tens position: Controls the behavior when an orientation axis with Hirth joint is
present.
Note:
This parameter is only evaluated for the "Tool alignment" function (i.e.
when the hundreds position has the value "0").
xx0x The axis position is rounded off to the nearest position.
xx1x The axis positions are rounded off so that the difference of
the β angle to its programmed value is minimal.
xx2x The axis positions are rounded off so that the β angle is equal
to the highest possible value which is less than the program‐
med value (β is rounded down).
xx3x The axis positions are rounded off so that the β angle is equal
to the lowest possible value which is greater than the pro‐
grammed value (β is rounded up).
Hundreds posi‐
tion:
Specifies which function is to be executed or the significance of the
two following parameters <W1> and <W2>.
x0xx "Tool alignment" function
Parameters <W1> and <W2> have the following meaning:
● <W1> = β
● <W2> = γ
The associated angles of the orientation axes are calculated.
x1xx "Direct tool alignment" function
<W1> is the position specification for the second orientation
axis, <W2> is the position specification for the third orienta‐
tion axis of a 6-axis transformation. The position of the first
orientation axis and the β and γ angles are defined which are
compatible with the two position specifications.
If no error occurs, two solutions are always output in the
$P_ORI_POS[<n>, <m>] system variables. The first index
<n> (0 or 1) refers to the solution and the second index <m>
(0 ... 2) to the orientation axis:
● $P_ORI_POS[0/1, 0]: Position of the first orientation axis
● $P_ORI_POS[0/1, 1]: Angle β
● $P_ORI_POS[0/1, 2]: Angle γ
A check is made as to whether the position specifications
<W1> and <W2> are compatible with any Hirth joints or active
software limits. If this is not the case, a corresponding error
number is returned (see <RetVal> parameter).
Work preparation
3.13 Tool offsets
NC programming
794 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
