• Slide in the keyboard tray (Fig. 47).
• For adjustments, open the mountings of the front plate and move front plate accordingly
(Fig. 48).
• Subsequently, tighten the mountings again.
• After sucessful adjustments, the keyboard tray should be identical with the (Fig. 49 and
Fig. 50).
Fig. 48 Sliding in the keyboard tray Fig. 49 Keyboard tray is not aligned as required
Fig. 50 Partial view of adjusted keyboard tray Fig. 51 Adjusted keyboard tray
