FUE1010 IP65 NEMA 4X

Operating Instructions, 12/2014, A5E03086491-AC

171

Technical data

11.1

Technical Data

Temperature Range

Degree of Protection

Operating: -18°C to 60°C (0°F to 140°F)

Storage: -20°C to 60°C (-4°F to 140°F)

IP65 (NEMA 4X)

Performance

The following specifications apply under standard conditions (i.e., measurements taken on a

straight run of 15 diameters upstream and 5 diameters downstream; flow rate above 1 fps;

non-aerated Newtonian liquids flowing at Reynolds numbers <2000 or >10000).

Table 11- 1 Performance Specifications

Transit-Time Accuracy At least ±1% to ±2 % of indicated flow (better

than ±0.5 % possible with calibration.)

Flow Sensitivity

0.0003 m/s (0.001 fps) - even at zero flow.

Zero Drift Stability

Less than 0.005 m/s (0.015 fps)

Batch Repeatability

±0.15 % of flow

Response Rate (Damping) SmartSlew effective from 0.2 seconds to 5

minutes.

Flow Velocity Range

Min. ±12 m/s (±40 ft/s), inc. zero flow

Linearity

0.001 m/s (0.003 ft/s)

Flow Profile Compensation Automatic Reynolds number correction of report-

ed flow rate.
