Functions
7.8 Analog Input Setup
FUE1010 IP65 NEMA 4X
118 Operating Instructions, 12/2014, A5E03086491-AC
Assigning a function to the voltage output:
1. From the [Analog Out Setup] menu, press <Right Arrow] to access the [Vo1] option list.
2. Move the cursor to the desired data function by pressing <Up/Down Arrow>.
3. To store selection press <ENTER>.
Note
Refer to drawing 1010N
-7-7 for Analog output connections.
The Pgen analog output is a buffered TTL-compliant pulse rate signal that varies linearly
from 0-5000 Hz in relation to to a selected data function.
Assigning a function to the Pgen output:
1. From the [Analog Out Setup] menu, press <Right Arrow> to access the [Pgen] option list.
2. Move the cursor to the desired data function by pressing <Up/Down Arrow>.
3. To store selection press <ENTER>.
Note
Some versions of the energy flow meter have the ability to read analog input signals. The
[Analog Inp Setup] menu cell is not displayed if the operating system of your model does not
include
this facility.
The optional Analog Input Setup function assigns an active analog input to a measurement
channel/path. The flow meter provides two DC current input ports for Dual Channel/Dual
Path units. These ports can be assigned to represent supply temperature, return
temperature or power consumption (see table below). The DC current input ranges from a
zero level of 4mA to a full scale of 20mA. The [Analog Inp Setup] menu cell allows you to
enable this port and then span it to any desired scaling (see table below).
Note
Refer to the Installation Drawings or I/O Module markings for the locations of these inputs
and wiring procedures.
